PETRO SMART
Model No. (PS-510)
Specially designed for Pertol / Ciesel pump, Motors & Compressor
The Need
A shared passive infrastructure provider is required to maintain the passive infrastructure to optimum levels of efficiency. And ensure that all the subsystems are efficiently run so that not only are there no site outages but an accurate cost control and monitoring of all component subsystems must be inbuilt.
The Solution
The petrol pump must run on a 24x7 basis and requires intelligent power management. Alternate power sources like diesel generators have a higer sitching time and the dispenser pump shuts down. Sudden power failure leads to loss of fuel, time and money of both the customer and the petrol pump owner. Managing energy consumption when dispensers are idle.
Benifits
Great power saving- Fuzzy Logic Control - a unique and advanced technology that protects the battery...
- Reduces frequency of water topping and enhances battery life.
- High and low input voltage protection
- Specially designed for Petrol / diesel pumps
A Specialized UPS for Diesel & Petrol Pumps
Specifications
| Product | Alpha Inverter |
|---|---|
| Capacity | 5-20 KVA |
| Technology | MOSFET / IGPBT-PWM |
| Input | SinglePhase / Three Phase |
| Voltage & Frequency | 230 AC/415 AC ±5% & 50Hz ±5% |
| Output | Three Phase |
| Waveform | Pure Sine Wave |
| Power Factor | 0.8% |
| Output Efficiency | >80% |
| Crest Factor | 1:3 |
| Battery | |
| Type | External Tubular / Valve Regulated Lead - Acid |
| Recharge Time | 8-12 Hours |
| Features | |
| Standard | Overload Reset & Front Panel LCD Panel |
| Optional | Spike & Surge Suppressor, Inverter Bypass & Software Control |
| Protection | |
| Charger | Voltage & Current Limiter, Phase Sequence & Failure Protector & Fuse/ Circuit Protector |
| Inverter | Over Voltage & Current Cut-off, Overload cut-off & ShortCircuit Protector |
| Battery | Battery Deep Discharge & Overcharge Cut-off & HRC Fuse /Circuit Breaker |
| Indication | |
| Visual | Mains, Charger, Inverter, Battery & Error Information |
| Audible | Changeover, Overload, Battery & Error Information |
| Environment | |
| Altitude | 0 – 2000m |
| Temperature | 0 – 40 C |
| Humidity | 95% Non-Condensing |
| Noise | <60dB |
