LIFT ON
Advantages
High Inrush Capability to handle Lift During Startup- Heavy Duty Inverter for Lift Applications
- Highly economical and cost effective compared to Gensets
- Output overload with auto reset & short circuit protection
- Output pure Sine wave with clear phase angle between two phases.
Salient Features
- Hign inrush / peak current handling capacity
- Pure sine wave output
- High frequency PWM inverter
- Crystal Controlled Output frequency Compact and well engineered architecture
- Smooth and silent operation
- Superior performance to price analysis
- Hign suitable for lifts with built in time delay, can also be used for 3 phase machines & motors
- Inbuilt input single phase preventer phase reversal and input low / high cut off
A Specialized UPS for Lifts & Elevators
Specifications
| Product | Alpha Inverter |
|---|---|
| Capacity | 7.5-30 KVA |
| Technology | MOSFET / IGPBT-PWM |
| Input | Three Phase |
| Voltage & Frequency | 230 AC/415 AC ±5% & 50Hz ±5% |
| Output | Three Phase |
| Voltage & Frequency | 400AC +_25% 50Hz +_1% |
| Waveform | Pure Sine Wave |
| Power Factor | 0.8% |
| Efficiency | >80% |
| Crest Factor | 1:3 |
| Battery | |
| Type | External Tubular / Valve Regulated Lead - Acid |
| Nominal Float Voltage | 192/240/360VDC |
| Recharge Time | 8-12 Hours |
| Features | |
| Standard | Overload Reset & Front Panel LCD Panel |
| Optional | Spike & Surge Suppressor, Inverter Bypass & Software Control |
| Protection | |
| Charger | Voltage & Current Limiter, Phase Sequence & Failure Protector & Fuse/ Circuit Protector |
| Inverter | Over Voltage & Current Cut-off, Overload cut-off & ShortCircuit Protector |
| Battery | Battery Deep Discharge & Overcharge Cut-off & HRC Fuse /Circuit Breaker |
| Indication | |
| Visual | Mains, Charger, Inverter, Battery & Error Information |
| Audible | Changeover, Overload, Battery & Error Information StatusEnvironment |
| Environment | |
| Altitude | 0 – 2000m |
| Temperature | 0 – 40 C |
| Humidity | 95% Non-Condensing |
| Noise | <60dB |
